Flexible doors are a cost-effective way to provide a swing door in openings for heavy traffic applications. The top-mounted gravity-operated hinge system allows the door to open fully and close automatically, allowing easy access and conserving energy. These doors are easy to install and virtually maintenance-free.
Features
Features
- Door Panel – These doors are constructed with a .160" thick PVC door body. Embossed finish resists scratches, scuffs, and abrasions. The approximate weight is 3 PSF. Available in your choice of Forest Green or Black with a variety of impact plate colors.
- Wipers – For a positive seal, balloon jamb edge seals and top and bottom wipers are provided.
- Leading Edge – 3" overlap at the center on bi-parting doors provides a noise and temperature barrier.
- Impact Plates – Optional 48" high textured PVC impact plates on both sides of the door panel are used to increase the strength and durability of the door panel. Available in forest green, navy, red, black, medium brown, chocolate brown, metallic gray, royal blue, beige, and dark gray.
- Windows – The viewing area is extra large to allow clear visibility and maximum safety.
- Top Mounted Gravity Hinge – Standard with the Chase top-mounted gravity hinging system that opens instantly upon contact, then closes automatically by gravity. Hinge features a zinc mounting bracket with stainless steel arm that is through-bolted to the panel.
Options
- Impact Plate
Of Note
- USDA Accepted
Designs and Colors
Disclaimer: Due to the variety in computer monitors, and lot to lot raw material variations these colors may not show an exact representation. Actual samples should always be requested if color accuracy or matching is key to your decision.
Downloads
Product Brochures
- AirGard 973 Flexible Door Data Sheet (291.364 KB)
Product Flyers
- Airgard 973 Order Form (128.482 KB)
Drawings
- AirGard 973 Single (161.821 KB)
- AirGard 973 Bi-Parting (167.166 KB)
- AirGard Valance (263.732 KB)
- AirGard Hole Location (17.357 KB)
- AirGard Parts Kit Drawing (361.835 KB)
Specs
- AirGard 973 Traffic Door CSI Specification (29.184 KB)
Install Instructions
- Flexible Door Installation Instructions (158.457 KB)
Maintenance Manuals
- AirGard 973 Maintenance Manual (49.412 KB)
